Dual flush

Geberit Type 290 flush valve d50, dual flush

My list (0)

Articles

Click on the icon with the 3 dots to have more options for each item.

Art. no.
282.352.21.1
Colour / surface

chrome / glossy

H

32 cm

Technical data

Storage temperature

≤ 40 °C

Water temperature max.

25 °C

Flush volume large, adjustment range

4–9 l

Flush volume small, adjustment range

2–4.5 l

Actuation force

18 N

Application purposes

Click on an application purpose to search more products

For ceramic cisterns with drilling ø 50 mmFor potable waterFor greywater and rainwater with pH value 5.5–9.5, if a filter system is used

Characteristics

Click on a characteristic to search more products

Dual flushHeight-adjustableSmall and large flush volume can be set depending on the amount of water in the cisternOverflow pipe height-adjustable
With lid attachmentSuitable for basket, for Type 280 flush valveSuitable for basket, for Type 250 flush valve (Twico 1)

Scope of delivery

  • Fastening material
