Geberit Monolith sanitary module for wall-hung WC, 101 cm, customer-specific
My list (0)
Technical data
Flow pressure 0.1–10 bar |
Operating temperature, water max. 25 °C |
Flush volume, factory setting 6 / 3 l |
Flush volume large, adjustment range 4.5 / 6 l |
Flush volume small 3 l |
Application purposes
Click on an application purpose to search more products
Characteristics
Click on a characteristic to search more products
Scope of delivery
Water supply connection set with 2 angle stop valves, 1/2"
Flush bend extension 160 mm
Sleeve made of EPDM, ø 44 / 55 mm
Straight connector made of PE-HD, ø 90 mm
Adaptor socket made of PE-HD, ø 90 / 110 mm
2 threaded rods M12
Base cover
6 fastening pins
Support frame
Fastening material for drywall
Fastening material
To order additionally
Set of cistern lid with side claddings, for Geberit Monolith sanitary module for wall-hung WC, 101 cm, customer-specific
Documents
Your input does not return any results
Spare parts
Geberit Monolith sanitary modules for floor-standing WC and wall-hung WC, 101 cm
Geberit Monolith sanitary modules for floor-standing WC and wall-hung WC, 101 cm
2016 -
| # | Art. no. | Description | Replacement for | Remarks |
|---|---|---|---|---|
| 1 | 243.440.TA.1 | Cistern lid for Geberit Monolith sanitary module for WC: aluminium brushed | 242.386.TA.1 | |
| 1 | 244.937.00.1 | Cistern lid for Geberit Monolith sanitary module for WC: black chrome / aluminium brushed | ||
| 2 | 245.509.00.1 | Mounting clip for Type 380 fill valve for Geberit Monolith sanitary module | ||
